31061103
ActiveMETZ CONNECT USA Inc.
TERM BLK 3P TOP ENTRY 3.5MM PCB
31061103
ActiveMETZ CONNECT USA Inc.
TERM BLK 3P TOP ENTRY 3.5MM PCB
Description
General part information
31061103
3 Position Wire to Board Terminal Block Vertical with Board 0.138" (3.50mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 31061103 |
|---|---|
| Clamp Material | Copper Alloy |
| Clamp Plating | Tin Plated |
| Color | Black |
| Contact Material | Copper Alloy |
| Current | 10 A |
| Features | Interlocking (Side) |
| Housing Material | Nylon 6/6, Polyamide, PA66 |
| Mating Orientation | Vertical with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.138 in |
| Plating | Tin Plated |
| Positions Per Level | 3 |
| Screw Plating | Zinc Plated |
| Screw Thread | M2 |
| Torque - Screw | 0.34 Nm |
| Voltage | 150 V |
| Wire Gauge (AWG) (Max) | 28 AWG |
| Wire Gauge (AWG) (Min) | 16 AWG |
| Wire Termination | Wire Guard, Screw, Leaf Spring |
