AMRM00101040220MA1
ActivePulse Electronics
IND 22UH SHLD 20% 4.5A
AMRM00101040220MA1
ActivePulse Electronics
IND 22UH SHLD 20% 4.5A
Description
General part information
AMRM00101040220MA1
22 µH Unshielded Inductor 4.5 A 66mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | AMRM00101040220MA1 |
|---|---|
| Current - Saturation (Isat) | 5 A |
| Current Rating | 4.5 A |
| DC Resistance (DCR) (Max) | 66 mOhm |
| Height - Seated (Max) | 0.157 in |
| Inductance | 22 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.457 in |
| Size / Dimension Width | 0.402 in |
| Tolerance | 20 % |
