3M AB5050 CIRCLE-1.5"-100

Obsolete

3M (TC)

RF EMI ABSORBER SHEET 1.5" 100PK

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Absorber Date Code Decipher

3M AB5050 CIRCLE-1.5"-100

Obsolete

3M (TC)

RF EMI ABSORBER SHEET 1.5" 100PK

Deep-Dive with AI

DocumentsDatasheet Absorber Date Code Decipher

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	3M AB5050 CIRCLE-1.5"-100

Adhesive	Single Sided, Non-Conductive
Material	Metal Flakes, Polymer Resin
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Shape	Circular
Thickness - Overall	0.022 in
Thickness - Overall	0.55 mm
Type	Absorbing Sheet
Width	38.1 mm
Width [x]	1.5 in

AB5050 Series

Part	Operating Temperature [Min]	Operating Temperature [Max]	Width [x]	Width	Adhesive	Type	Thickness - Overall [custom]	Thickness - Overall [custom]	Length	Length	Shape	Material	Width [y]	Width [y]	Length [x]	Width	Thickness - Overall	Thickness - Overall
3M (TC) 3M AB5050 1.5" X 9.25"-100	-25 °C	85 °C	1.5 in	38.1 mm	Acrylic Pressure Sensitive Adhesive (PSA) Non-Conductive	Absorbing Sheet	0.5 mm	0.02 "	9.25 inches	234.95 mm	Rectangular	Metal Flakes Polymer Resin
3M (TC) 3M AB5050 0.5" X 7"-250	-25 °C	85 °C			Acrylic Pressure Sensitive Adhesive (PSA) Non-Conductive	Absorbing Sheet	0.5 mm	0.02 "	7 in	177.8 mm	Rectangular	Metal Flakes Polymer Resin
3M (TC) 3M AB5050 2" X 1.25"-100	-25 °C	85 °C			Acrylic Pressure Sensitive Adhesive (PSA) Non-Conductive	Absorbing Sheet	0.5 mm	0.02 "	2 in	50.8 mm	Rectangular	Metal Flakes Polymer Resin	31.75 mm	1.25 in
3M (TC) 3M AB5050 4.13" X 1.25"-25	-25 °C	85 °C			Acrylic Pressure Sensitive Adhesive (PSA) Non-Conductive	Absorbing Sheet	0.5 mm	0.02 "		104.9 mm	Rectangular	Metal Flakes Polymer Resin	31.75 mm	1.25 in	4.13 "
3M (TC) 3M AB5050 4.13" X 6"-25	-25 °C	85 °C		104.9 mm	Acrylic Pressure Sensitive Adhesive (PSA) Non-Conductive	Absorbing Sheet	0.5 mm	0.02 "	6 in	152.4 mm	Rectangular	Metal Flakes Polymer Resin				4.13 in
3M (TC) 3M AB5050 0.75" X 1.5"-250	-25 °C	85 °C			Acrylic Pressure Sensitive Adhesive (PSA) Non-Conductive	Absorbing Sheet	0.5 mm	0.02 "	1.5 "	38.1 mm	Rectangular	Metal Flakes Polymer Resin	19.05 mm	0.75 in
3M (TC) 3M AB5050 0.75" X 1.25"-250	-25 °C	85 °C			Acrylic Pressure Sensitive Adhesive (PSA) Non-Conductive	Absorbing Sheet	0.5 mm	0.02 "	1.25 in	31.75 mm	Rectangular	Metal Flakes Polymer Resin	19.05 mm	0.75 in
3M (TC) 3M AB5050 CIRCLE-0.938"-250	-25 °C	85 °C			Non-Conductive Single Sided	Absorbing Sheet	0.5 mm	0.02 "			Circular	Metal Flakes Polymer Resin	23.83 mm	0.938 in
3M (TC) 3M AB5050 CIRCLE-0.688"-250	-25 °C	85 °C			Non-Conductive Single Sided	Absorbing Sheet	0.5 mm	0.02 "			Circular	Metal Flakes Polymer Resin	17.48 mm	0.688 in
3M (TC) 3M AB5050 CIRCLE-1.5"-100	-25 °C	85 °C	1.5 in	38.1 mm	Non-Conductive Single Sided	Absorbing Sheet					Circular	Metal Flakes Polymer Resin					0.022 in	0.55 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

AB5050 Series

RF EMI Absorbing Sheet AB-5000 Polymer Resin, Metal Flakes Non-Conductive, Single Sided 1.500" (38.10mm) X X 0.022" (0.55mm)
