Technical Specifications
Parameters and characteristics for this part
| Specification | C911U102MVWDCAWL50 |
|---|---|
| Applications | Safety |
| Capacitance | 1000 pF |
| Height - Seated (Max) | 0.512 in |
| Lead Spacing | 0.394 in |
| Lead Style | Formed Leads - Kinked |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Disc, Radial |
| Ratings | X1, Y1 |
| Size / Dimension Diameter | 0.315 in |
| Temperature Coefficient | Y5U (E) |
| Tolerance | 20 % |
| Voltage - Rated | 400 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | Updated |
|---|---|---|---|---|
| Digikey | Tape & Box (TB) | 10000 | $ 0.16 | <6d |
CAD
3D models and CAD resources for this part
Description
General part information
C911U102MVWDCAWL50
1000 pF ±20% 400VAC Ceramic Capacitor Y5U (E) Radial, Disc
Documents
Technical documentation and resources
