Description
General part information
FLLCC800A055I1
0.5 µF Feed Through Capacitor 750V 800 A Axial - Threaded Terminals
Technical Specifications
Parameters and characteristics for this part
| Specification | FLLCC800A055I1 |
|---|---|
| Capacitance | 0.5 µF |
| Current | 800 A |
| Insertion Loss | 60 dB |
| Mounting Type | Bolt Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Axial - Threaded Terminals |
| Size / Dimension Diameter | 2.165 in |
| Size / Dimension Length | 3.15 in |
| Thread Size | M25 |
| Type | Feed Through |
| Voltage - Rated | 750 VAC |
