| Applications | Instrumentation, Energy, Lighting, Telecommunications | Instrumentation, Energy, Lighting, Telecommunications |
| Backshell Material, Plating | Polyamide (PA), Nylon | Polyamide (PA), Nylon |
| Cable Diameter | - | 6 mm |
| Cable Diameter | - | 6 mm |
| Cable Diameter | - | 0.12 in |
| Cable Diameter | - | 3 mm |
| Cable Diameter | - | 0.24 in |
| Color | Black | Black |
| Connector Type | Female Sockets, Plug | Female Sockets, Plug, Plug Housing, Male Pins, Housing for Prewired RJ45 Cordset |
| Contact Finish - Mating | Gold | Gold |
| Contact Finish Thickness - Mating | 16 Áin | 16 Áin |
| Contact Finish Thickness - Mating | 0.41 Ám | 0.41 Ám |
| Contact Material | Brass | Brass, Copper Alloy |
| Contact Shape | - | Circular |
| Contact Size | - | 8 - 20 |
| Contact Size | - | 20 (3), 16 (3), 16 (4), 12 (4), 12 (2), 20 (2) |
| Contact Type | - | Crimp |
| Current Rating (Amps) | 10 A | 4 - 13 A |
| Fastening Type | Bayonet Lock | Bayonet Lock |
| Features | Coupling Nut, UV Resistant, Backshell | Coupling Nut, UV Resistant, Backshell, Circular Bayonet Coupling, Toolless, Vibration Resistant |
| For Use With/Related Products | - | LC Connectors, MPO Plugs |
| Housing Color | - | Black |
| Housing Material | - | Plastic, Thermoplastic |
| Ingress Protection | IP68, IP69K | IP68, IP69K, IP67/IP68 - Dust Tight, Waterproof, IP68 - Dust Tight, Waterproof |
| Insert Material | Polychloroprene | Polychloroprene, Nylon, Polyamide (PA) |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mating Cycles | - | 250 |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Note | - | Contacts Not Included, Plug Not Provided |
| Number of Positions | 4 | 2 - 23 |
| Number of Positions | - | 2 |
| Number of Positions | - | 3 |
| Number of Positions | - | 1 |
| Number of Positions | - | 1 |
| Number of Positions | - | 6 |
| Number of Positions | - | 2 |
| Operating Temperature [Max] | 105 ░C | 105 ░C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Orientation | N | N, Z, Y, W, X |
| Primary Material | Plastic | Plastic |
| Shell Size - Insert | 12-4 | 10-7, 10-6, 12-4, 14-12, 18X2, 12-8, 10-3W3, 10-3, 14-8, 8-2, 12-3, 18-3, 10-4, 8-4, 14-5, 10-2W2, 8-33, 12-2, 8-3, 14-2 |
| Shell Size - Insert | - | 7 - 18 |
| Shell Size - Insert | - | 14 - 98 |
| Shell Size - Insert | - | 19 - 23 |
| Shell Size - Insert | - | 14 - 18 |
| Shielding | Unshielded | Unshielded |
| Simplex/Duplex | - | Duplex, Simplex |
| Termination | - | Screw |
| Type | - | For Female Sockets, For Male Pins |
| Voltage Rating | 500 V | 250 - 650 VDC |
