Specification	6026215

Adjustment Type	Teaching Method
Cable Length	78.74 in
Connection Method	Cable
Ingress Protection	IP67
Light Source	Infrared
Light Source Wavelength (Infrared)	880 nm
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-25 °C
Output Configuration	Light-ON, PNP - Dark-ON
Response Time	1.25 ms
Sensing Distance Maximum	13.386 "
Sensing Distance Minimum	0 cm
Sensing Method	Proximity
Voltage - Supply (Maximum)	30 VDC
Voltage - Supply (Minimum)	10 VDC
