JC24S-250A-V
ActiveAim Dynamics
24MM CURRENT TRANS 250A:5VDC
JC24S-250A-V
ActiveAim Dynamics
24MM CURRENT TRANS 250A:5VDC
Description
General part information
JC24S-250A-V
Current Sensor 250A 1 Channel Current Sensor Module, Single Pass Through
Technical Specifications
Parameters and characteristics for this part
| Specification | JC24S-250A-V |
|---|---|
| Accuracy | 2 % |
| Current - Sensing | 250 A |
| For Measuring | AC |
| Frequency (Max) | 60 Hz |
| Frequency (Min) | 50 Hz |
| Linearity Tolerance | 2 % |
| Mounting Type | Free Hanging |
| Number of Channels | 1 |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -20 °C |
| Output | Ratiometric |
| Output Voltage Range 1 (Max) | 5 V |
| Output Voltage Range 1 (Min) | 0 V |
| Package / Case | Module, Single Pass Through |
| Response Time | 300 ms |
| Sensor Type | Current Sensor |
