75082
ActiveWASHER SEALING, STAINLESS STEEL, 25.4 MM
75082
ActiveWASHER SEALING, STAINLESS STEEL, 25.4 MM
Description
General part information
75082
The 75082 is a SEELOC® self-sealing Washer made of stainless steel. It is designed for use with regular screws or bolts for sealing panels and cases having large clearance holes or slots and can also be used to seal openings of protrusions as shown below. Upon tightening, a seal is formed under the head of the screw or bolt as well as around the periphery of the washer face.
Technical Specifications
Parameters and characteristics for this part
| Specification | 75082 |
|---|---|
| Diameter - Inside (Maximum) | 0.25 in |
| Diameter - Inside (Nominal) | 0.25 in |
| Diameter - Outside | 1 in |
| Diameter - Outside (Rounded) | 1 in |
| Material | Stainless Steel |
| Thickness | 0.078 in |
| Thread/Screw/Hole Size | 0.25 in |
| Thread/Screw/Hole Size | 1/4" |
| Type | Sealing |
