LC1K12105B7
ActiveSCHNEIDER ELECTRIC
CONTACTOR
LC1K12105B7
ActiveSCHNEIDER ELECTRIC
CONTACTOR
Description
General part information
LC1K12105B7
CONTACTOR
Technical Specifications
Parameters and characteristics for this part
| Specification | LC1K12105B7 |
|---|---|
| Coil Voltage | 24 VDC |
| Contact Form | A, PST-NO, Form, 3 |
| Contact Rating (Current) | 12 A |
| Features | Auxiliary Contacts |
| Mounting Type | Through Hole |
| Must Operate Voltage | 19.2 V |
| Must Release Voltage | 4.8 VAC |
| Operate Time | 20 ms |
| Pin Count | 3 pins |
| Release Time | 20 ms |
| Switching Voltage AC (Max) | 690 VAC |
| Termination Style | PC Pins |
