B82141A1224J000
ActiveEPCOS - TDK Electronics
FIXED IND 220UH 130MA 5.8 OHM TH
B82141A1224J000
ActiveEPCOS - TDK Electronics
FIXED IND 220UH 130MA 5.8 OHM TH
Description
General part information
B82141A1224J000
220 µH Unshielded Drum Core, Wirewound Inductor 130 mA 5.8Ohm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | B82141A1224J000 |
|---|---|
| Current Rating | 0.13 A |
| DC Resistance (DCR) (Max) | 5.8 Ohm |
| Frequency - Self Resonant | 3.8 MHz |
| Inductance | 220 µH |
| Inductance Frequency - Test | 796 kHz |
| Material - Core | Ferrite |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Q | 60 |
| Shielding | Unshielded |
| Size / Dimension Diameter | 0.118 in |
| Size / Dimension Length | 0.268 in |
| Tolerance | 5 % |
| Type | Drum Core, Wirewound |
