DSPIC30F3012-30I/P
ActiveMicrochip Technology
MCU 16-BIT DSPIC30 DSPIC RISC 24KB FLASH 3.3V/5V 18-PIN PDIP TUBE
Deep-Dive with AI
Search across all available documentation for this part.
DSPIC30F3012-30I/P
ActiveMicrochip Technology
MCU 16-BIT DSPIC30 DSPIC RISC 24KB FLASH 3.3V/5V 18-PIN PDIP TUBE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DSPIC30F3012-30I/P | dsPIC30F3012 Series |
|---|---|---|
| - | - | |
| Connectivity | I2C, SPI, UART/USART | I2C, SPI, UART/USART |
| Core Processor | dsPIC | dsPIC |
| Core Size | 16-Bit | 16-Bit |
| Data Converters [custom] | 12 b | 12 b |
| Data Converters [custom] | 8 | 8 |
| Mounting Type | Through Hole | Surface Mount, Through Hole |
| Number of I/O | 12 | 12 |
| Operating Temperature [Max] | 85 °C | 85 - 125 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Oscillator Type | Internal | Internal |
| Package / Case | 18-DIP | 18-SOIC, 44-VQFN Exposed Pad, 18-DIP |
| Package / Case | - | 0.295 in |
| Package / Case | - | 7.5 mm |
| Package / Case [x] | 0.3 in | 0.3 in |
| Package / Case [x] | 7.62 mm | 7.62 mm |
| Program Memory Size | 24 KB | 24 KB |
| Program Memory Type | FLASH | FLASH |
| RAM Size | 2K x 8 | 2K x 8 |
| Speed | 30 MIPs | 20 - 30 MIPs |
| Supplier Device Package | 18-PDIP | 18-SOIC, 44-QFN (8x8), 18-PDIP |
| Voltage - Supply (Vcc/Vdd) [Max] | 5.5 V | 5.5 V |
| Voltage - Supply (Vcc/Vdd) [Min] | 2.5 V | 2.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 5.75 | |
| 25 | $ 5.20 | |||
| 100 | $ 5.00 | |||
| Microchip Direct | TUBE | 1 | $ 5.75 | |
| 25 | $ 5.20 | |||
| 100 | $ 4.73 | |||
| 1000 | $ 4.35 | |||
| 5000 | $ 4.13 | |||
dsPIC30F3012 Series
MCU 16-BIT DSPIC30 DSPIC RISC 24KB FLASH 3.3V/5V 18-PIN SOIC W TUBE
| Part | Program Memory Type | Program Memory Size | Supplier Device Package | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case [y] | Package / Case [y] | Package / Case | RAM Size | Mounting Type | Data Converters [custom] | Data Converters [custom] | Voltage - Supply (Vcc/Vdd) [Min] | Voltage - Supply (Vcc/Vdd) [Max] | Connectivity | Speed | Number of I/O | Core Processor | Oscillator Type | Core Size | Package / Case [x] | Package / Case [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Microchip Technology DSPIC30F3012-20E/SO | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012-30I/SO | FLASH | 24 KB | 18-SOIC | 85 °C | -40 °C | 0.295 in | 7.5 mm | 18-SOIC | 2K x 8 | Surface Mount | 12 b | 8 | 2.5 V | 5.5 V | I2C, SPI, UART/USART | 30 MIPs | 12 | dsPIC | Internal | 16-Bit | ||
Microchip Technology DSPIC30F3012-20E/ML | FLASH | 24 KB | 44-QFN (8x8) | 125 °C | -40 °C | 44-VQFN Exposed Pad | 2K x 8 | Surface Mount | 12 b | 8 | 2.5 V | 5.5 V | I2C, SPI, UART/USART | 20 MIPS | 12 | dsPIC | Internal | 16-Bit | ||||
Microchip Technology DSPIC30F3012-20E/ML | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012-20I/ML | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012T-20I/ML | FLASH | 24 KB | 44-QFN (8x8) | 85 °C | -40 °C | 44-VQFN Exposed Pad | 2K x 8 | Surface Mount | 12 b | 8 | 2.5 V | 5.5 V | I2C, SPI, UART/USART | 20 MIPS | 12 | dsPIC | Internal | 16-Bit | ||||
Microchip Technology DSPIC30F3012-20E/SO | FLASH | 24 KB | 18-SOIC | 125 °C | -40 °C | 0.295 in | 7.5 mm | 18-SOIC | 2K x 8 | Surface Mount | 12 b | 8 | 2.5 V | 5.5 V | I2C, SPI, UART/USART | 20 MIPS | 12 | dsPIC | Internal | 16-Bit | ||
Microchip Technology DSPIC30F3012-30I/ML | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012-20I/ML | FLASH | 24 KB | 44-QFN (8x8) | 85 °C | -40 °C | 44-VQFN Exposed Pad | 2K x 8 | Surface Mount | 12 b | 8 | 2.5 V | 5.5 V | I2C, SPI, UART/USART | 20 MIPS | 12 | dsPIC | Internal | 16-Bit | ||||
Microchip Technology DSPIC30F3012-20I/SO | FLASH | 24 KB | 18-SOIC | 85 °C | -40 °C | 0.295 in | 7.5 mm | 18-SOIC | 2K x 8 | Surface Mount | 12 b | 8 | 2.5 V | 5.5 V | I2C, SPI, UART/USART | 20 MIPS | 12 | dsPIC | Internal | 16-Bit | ||
Microchip Technology DSPIC30F3012-20E/SO | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012-20I/ML | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012-30I/SO | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012-20I/P | FLASH | 24 KB | 18-PDIP | 85 °C | -40 °C | 18-DIP | 2K x 8 | Through Hole | 12 b | 8 | 2.5 V | 5.5 V | I2C, SPI, UART/USART | 20 MIPS | 12 | dsPIC | Internal | 16-Bit | 0.3 in | 7.62 mm | ||
Microchip Technology DSPIC30F3012-30I/ML | FLASH | 24 KB | 44-QFN (8x8) | 85 °C | -40 °C | 44-VQFN Exposed Pad | 2K x 8 | Surface Mount | 12 b | 8 | 2.5 V | 5.5 V | I2C, SPI, UART/USART | 30 MIPs | 12 | dsPIC | Internal | 16-Bit | ||||
Microchip Technology DSPIC30F3012-30I/P | FLASH | 24 KB | 18-PDIP | 85 °C | -40 °C | 18-DIP | 2K x 8 | Through Hole | 12 b | 8 | 2.5 V | 5.5 V | I2C, SPI, UART/USART | 30 MIPs | 12 | dsPIC | Internal | 16-Bit | 0.3 in | 7.62 mm | ||
Microchip Technology DSPIC30F3012-20E/ML | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012-30I/P | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012-20I/SO | ||||||||||||||||||||||
Microchip Technology DSPIC30F3012-30I/SO |
Description
General part information
dsPIC30F3012 Series
dsPIC30F Sensor Family 16-bit Digital Signal Controller
