CBM-A232S-225-481
ActiveSame Sky (Formerly CUI Devices)
FAN BLOWER 119.3X32MM 24VDC WIRE
CBM-A232S-225-481
ActiveSame Sky (Formerly CUI Devices)
FAN BLOWER 119.3X32MM 24VDC WIRE
Description
General part information
CBM-A232S-225-481
Fan Blower 24VDC Square/Rounded - 119.3mm L x 119mm H Ball 23.1 CFM (0.647mł/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CBM-A232S-225-481 |
|---|---|
| Air Flow | 23.1 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Current Rating | 360 mA |
| Fan Type | Blower |
| Features | Auto Restart |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 48.2 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 8.64 W |
| RPM | 2500 RPM |
| Size / Dimension Height | 119 mm |
| Size / Dimension Length | 119.3 mm |
| Size / Dimension Shape | Square/Rounded |
| Static Pressure | 0.94 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 24 VAC |
| Voltage Range (Max) | 5.5 VDC |
| Voltage Range (Min) | 4.5 VDC |
| Width | 32 mm |
