Specification	5530843-4

Card Thickness (Max)	0.07 in
Card Thickness (Min)	0.054 in
Card Type	Non Specified, Dual Edge
Color	Black
Contact Finish	Gold
Contact Finish Thickness	30 µin
Contact Material	Phosphor Bronze
Gender	Female
Material - Insulation	Polyester, Glass Filled
Mounting Type	Through Hole
Number of Positions	44
Number of Rows	2
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-55 °C
Pitch	0.1 in
Read Out	Dual
Termination	Solder

5530843 Series

Part	Material - Insulation	Number of Positions	Contact Finish Thickness	Pitch	Color	Mounting Type	Contact Finish	Operating Temperature (Min)	Operating Temperature (Max)	Termination	Contact Material	Read Out	Gender	Number of Rows	Card Type	Card Thickness (Min)	Card Thickness (Max)
TE Connectivity AMP Connectors 8-5530843-8	Glass Filled Polyester	40	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
TE Connectivity AMP Connectors 5530843-1	Glass Filled Polyester	24 pos	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
TE Connectivity AMP Connectors 6-5530843-5	Glass Filled Polyester	62	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
TE Connectivity AMP Connectors 8-5530843-3	Glass Filled Polyester	24 pos	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
TE Connectivity AMP Connectors 7-5530843-7	Glass Filled Polyester	6	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
TE Connectivity AMP Connectors 5-5530843-0	Glass Filled Polyester	20	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
TE Connectivity AMP Connectors 5-5530843-3	Glass Filled Polyester	34	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
TE Connectivity AMP Connectors 5530843-3	Glass Filled Polyester	36	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
TE Connectivity AMP Connectors 5530843-2	Glass Filled Polyester	30	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
TE Connectivity AMP Connectors 7-5530843-5	Glass Filled Polyester	12	30 µin	0.1 in	Black	Through Hole	Gold	-55 °C	85 °C	Solder	Phosphor Bronze	Dual	Female	2	Dual Edge Non Specified	0.054 in	0.07 in
