Specification	ADJ14005

Approval Agency	CQC, VDE, cURus
Coil Current	50 mA
Coil Type	Dual Coil, Latching
Coil Voltage	5 V
Contact Form	C, 1, SPDT, Form
Contact Material	Silver Tin Oxide (AgSnO)
Contact Rating (Current)	16 A
Load - Max Switching (Apparent Power)	4000 VA
Mounting Type	Through Hole
Must Operate Voltage	3.5 VDC
Operate Time	20 ms
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-40 °C
Relay Type	General Purpose
Release Time	20 ms
Seal Rating	Fully, Sealed
Switching Voltage AC (Max)	250 VAC
Termination Style	PC Pin
