FH52K-12(6)SA-1SH
ActiveHirose Electric Co Ltd
CONN FFC FPC BOTTOM 12POS 1MM RA
FH52K-12(6)SA-1SH
ActiveHirose Electric Co Ltd
CONN FFC FPC BOTTOM 12POS 1MM RA
Description
General part information
FH52K-12(6)SA-1SH
CONN FFC FPC BOTTOM 12POS 1MM RA
Technical Specifications
Parameters and characteristics for this part
| Specification | FH52K-12(6)SA-1SH |
|---|---|
| Actuator Material | Halogen Free, Liquid Crystal Polymer (LCP) |
| Cable End Type | Tabbed |
| Connector/Contact Type | Contacts, Bottom |
| Contact Finish | Gold |
| Contact Material | Copper Alloy |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| FFC, FCB Thickness | 0.3 mm |
| Flat Flex Type | FFC, FPC |
| Height Above Board | 0.079 in |
| Housing Material | LCP, Liquid Crystal Polymer, Halogen Free |
| Locking Feature | Flip Lock |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Right Angle, Surface Mount |
| Number of Positions (Loaded) | 6 |
| Number of Positions (Total) | 12 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.039 in |
| Termination | Solder |
| Voltage Rating | 50 V |
