DL-PS-90/24-CL2
ActiveJESCO Lighting Group
90W INDOOR ELECTRONIC CLASS 2 &
DL-PS-90/24-CL2
ActiveJESCO Lighting Group
90W INDOOR ELECTRONIC CLASS 2 &
Description
General part information
DL-PS-90/24-CL2
3.75A 24V LED Driver AC DC Converter Topology 1 Output
Technical Specifications
Parameters and characteristics for this part
| Specification | DL-PS-90/24-CL2 |
|---|---|
| Approval Agency | cULus |
| Current - Output (Max) | 3.75 A |
| Efficiency | 91 % |
| Features | OCP, SCP, OTP, OVP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -40 °C |
| Power (Watts) | 90 W |
| Ratings | IP67 |
| Size / Dimension Height | 1.5 in |
| Size / Dimension Length | 6.75 in |
| Size / Dimension Width | 2.5 in |
| Termination I.D. | 2.1 mm |
| Termination Length | 11 mm, 2.1 mm |
| Termination O.D. | 5.5 mm |
| Termination Style | Barrel Plug |
| Topology | AC DC Converter |
| Voltage - Input (Max) | 264 V |
| Voltage - Input (Min) | 90 VAC |
| Voltage - Output | 24 V |
