Description
General part information
GNSS4GSM
RF ANTENNA 2G, 3G, 5G, Bluetooth, Cellular, GNSS, GPS, ISM, LoRa, LPWAN, LTE, Wi-Fi Module SMA Male (2) Stud, Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | GNSS4GSM |
|---|---|
| Antenna Type | Module |
| Applications | LPWAN, 3G, Bluetooth, GNSS, LoRa, 5G, Wi-Fi, Cellular, ISM, LTE, GPS, 2G |
| Features | Cable, LNA, 5m |
| Frequency (Band) | 2.205 GHz |
| Frequency (Center) | 829 MHz |
| Frequency Group | UHF |
| Frequency Group Maximum (UHF) | 3 GHz, 1 GHz |
| Frequency Group Minimum (UHF) | 2 GHz, 300 MHz |
| Frequency Range (Band 1) Maximum | 960 MHz |
| Frequency Range (Band 1) Minimum | 698 MHz |
| Frequency Range (Band 2) Maximum | 2.7 GHz |
| Frequency Range (Band 2) Minimum | 1.71 GHz |
| Gain | 5 dBi |
| Height (Max) | 5.906 in |
| Ingress Protection | IP67 |
| Mounting Type | Stud, Through Hole |
| Number of Bands | 2 |
| RF Family/Standard | Navigation, Cellular |
| Termination Count (SMA Male) | 2 |
| Termination Type | SMA Male |
| VSWR | 2 |
