0600-00056
ActiveTE Connectivity AMP Connectors
RF ANT 2.4GHZ PCB TRACE IPEX ADH
0600-00056
ActiveTE Connectivity AMP Connectors
RF ANT 2.4GHZ PCB TRACE IPEX ADH
Description
General part information
0600-00056
RF ANTENNA PCB Trace U.FL (UMCC), I-PEX MHF4 Adhesive
Technical Specifications
Parameters and characteristics for this part
| Specification | 0600-00056 |
|---|---|
| Antenna Type | PCB Trace |
| Frequency (Center/Band) | 2.4 GHz |
| Frequency Group | UHF |
| Frequency Group Maximum (UHF) | 3 GHz |
| Frequency Group Minimum (UHF) | 2 GHz |
| Frequency Range (Max) | 2.5 GHz |
| Frequency Range (Min) | 2.4 GHz |
| Gain | 2.2 dBi |
| Height (Max) | 0.236 in |
| Mounting Type | Adhesive |
| Number of Bands | 1 |
| Power - Max | 1 VA |
| Return Loss | -10 dB |
| Termination | I-PEX MHF4, U.FL (UMCC) |
| VSWR | 2 |
