Description
General part information
RPSMA-LR-0.66AS(Au)
RP-SMA Connector Jack, Male Pin 50 Ohms Through Hole, Right Angle Crimp
Technical Specifications
Parameters and characteristics for this part
| Specification | RPSMA-LR-0.66AS(Au) |
|---|---|
| Body Finish | Gold |
| Body Material | Brass |
| Cable Group | Coaxial Cable |
| Cable Group Size | 1.32 mm |
| Center Contact Material | Brass |
| Center Contact Plating | Gold |
| Connector Style | RP-SMA |
| Connector Type | Jack, Male Pin |
| Contact Termination | Crimp |
| Fastening Type | Threaded |
| Frequency - Max | 6000 MHz |
| Housing Color | Gold |
| Impedance | 50 Ohm |
| Mounting Type | Through Hole, Right Angle |
| Number of Ports | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Shield Termination | Solder |
