282838-6
ActiveTE Connectivity AMP Connectors
TERM BLK 6P SIDE ENTRY 10MM PCB
282838-6
ActiveTE Connectivity AMP Connectors
TERM BLK 6P SIDE ENTRY 10MM PCB
Description
General part information
282838-6
6 Position PCB Terminal Block, Header, Wire-to-Board, 10 mm [.394 in] Centerline, 1 Row, 90° Wire Entry Angle, 30 – 16 AWG, .05 – 1.3 mm² Wire
Technical Specifications
Parameters and characteristics for this part
| Specification | 282838-6 |
|---|---|
| Color | Green |
| Current | 13.5 A |
| Features | Interlocking (Side) |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Pitch | 0.394 in |
| Positions Per Level | 6 |
| Voltage | 600 V |
| Wire Gauge (AWG) (Max) | 30 AWG |
| Wire Gauge (AWG) (Min) | 16 AWG |
| Wire Termination | Rising Cage Clamp, Screw |
