BSH1403T01A2P
ActiveSCHNEIDER ELECTRIC
MOTOR 140 IP40 SMOOTH INC NOBRK
BSH1403T01A2P
ActiveSCHNEIDER ELECTRIC
MOTOR 140 IP40 SMOOTH INC NOBRK
Description
General part information
BSH1403T01A2P
AC Motor Servomotor 4800 RPM 4.1kW 480VAC
Technical Specifications
Parameters and characteristics for this part
| Specification | BSH1403T01A2P |
|---|---|
| Diameter - Shaft | 0.945 in |
| Function | Servomotor |
| Length - Shaft and Bearing | 1.969 in |
| Mounting Hole Spacing | 5.118 in |
| Power - Rated | 4.1 kW |
| RPM | 4800 RPM |
| Size / Dimension Length | 5.512 in |
| Size / Dimension Shape | Square |
| Size / Dimension Width | 5.512 in |
| Termination Style | Connector |
| Torque - Rated (mNm) | 12900 mNm |
| Torque - Rated (oz-in) | 1826.8 oz-in |
| Type | AC Motor |
| Voltage - Rated | 480 VAC |
