Description
General part information
EF2A-D150B-1
DIN RAIL TERMINAL BLOCKS
Technical Specifications
Parameters and characteristics for this part
| Specification | EF2A-D150B-1 |
|---|---|
| Current - UL | 175 A |
| Housing Color | Black |
| Mounting Type | DIN Rail |
| Number of Levels | 1 |
| Number of Positions | 1 |
| Terminal Width | 40.5 mm |
| Termination Style | Push In, Spring |
| Type | Bus Bar - Side |
| Voltage - UL | 600 V |
| Wire Gauge or Range - mm² (Maximum) | 60 mm² |
| Wire Gauge or Range - mm² (Minimum) | 22 mm² |
