Description
General part information
V24ZA50
23 V 2 kA Varistor 1 Circuit Through Hole Disc 20mm
Technical Specifications
Parameters and characteristics for this part
| Specification | V24ZA50 |
|---|---|
| Capacitance | 18 pF |
| Current - Surge | 2 kA |
| Energy | 100 J |
| Maximum AC Volts | 14 V |
| Maximum DC Voltage | 18 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -55 °C |
| Package Diameter | 20 mm |
| Package Name | Disc |
| Varistor Voltage (Max) | 25.3 V |
| Varistor Voltage (Min) | 20.7 V |
| Varistor Voltage (Typ) | 23 V |
