VTX-146-500-255
ActiveVigortronix
500VA TOROIDAL TRANSFORMER 2X55V
VTX-146-500-255
ActiveVigortronix
500VA TOROIDAL TRANSFORMER 2X55V
Description
General part information
VTX-146-500-255
500VA TOROIDAL TRANSFORMER 2X55V
Technical Specifications
Parameters and characteristics for this part
| Specification | VTX-146-500-255 |
|---|---|
| Center Tap | No |
| Current - Output (Max) | 4.55 A |
| Height - Seated (Max) | 61 mm |
| Mounting Type | Chassis Mount |
| Power - Max | 500 VA |
| Primary Winding(s) | Dual |
| Secondary Winding(s) | Dual |
| Size / Dimension Diameter | 138 mm |
| Termination Style | Wire Leads |
| Type | Toroidal |
| Voltage - Isolation | 4200 VDC |
| Voltage - Primary | 230V, 115V |
| Voltage - Secondary (Full Load) (Parallel) | 55 V |
| Voltage - Secondary (Full Load) (Series) | 110 V |
| Weight | 9.4 lbs |
