XR-Z14-CW2P6
ObsoleteDigi International
XBEE ZB RANGE EXTENDER US PLUG
XR-Z14-CW2P6
ObsoleteDigi International
XBEE ZB RANGE EXTENDER US PLUG
Description
General part information
XR-Z14-CW2P6
802.15.4 Zigbee™ Transceiver, ZigBee™
Technical Specifications
Parameters and characteristics for this part
| Specification | XR-Z14-CW2P6 |
|---|---|
| Applications | Energy Measurement |
| Data Rate (Max) | 250 kBaud |
| Features | US Power Cord |
| Frequency | 2.4 GHz |
| Function | ZigBee™, Transceiver |
| Modulation or Protocol | 802.15.4 Zigbee™ |
| Power - Output | 18 dBm |
| Sensitivity | -102 dBm |
| Voltage - Supply | 120 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
