M39014/05-2131
ActiveKYOCERA AVX
CKR MOLDED AXIAL ROHS COMPLIANT: YES
M39014/05-2131
ActiveKYOCERA AVX
CKR MOLDED AXIAL ROHS COMPLIANT: YES
Description
General part information
M39014/05-2131
1 µF ±10% 100V Ceramic Capacitor BR Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | M39014/05-2131 |
|---|---|
| Applications | High Reliability |
| Capacitance | 1 µF |
| Failure Rate (Percent) | 0.01 % |
| Failure Rate Rating | R |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Size / Dimension Diameter | 0.35 in |
| Size / Dimension Length | 0.69 in |
| Temperature Coefficient | BR |
| Tolerance | 10 % |
| Voltage - Rated | 100 VAC/DC |
