XBP24CAPIS-001
ObsoleteDigi International
RF TXRX MOD 802.15.4 TH SMD
XBP24CAPIS-001
ObsoleteDigi International
RF TXRX MOD 802.15.4 TH SMD
Description
General part information
XBP24CAPIS-001
802.15.4 Transceiver Module 2.4GHz Integrated, Trace Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | XBP24CAPIS-001 |
|---|---|
| Antenna Type | Integrated, Trace |
| Current - Receiving | 31 mA |
| Current - Transmitting | 120 mA |
| Data Rate | 1 Mbps |
| Frequency | 2.4 GHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Module |
| Power - Output | 18 dBm |
| RF Family/Standard | 802.15.4 |
| Sensitivity | -101 dBm |
| Serial Interfaces | SPI, UART |
| Utilized IC / Part | EM357 |
| Voltage - Supply (Maximum) | 3.6 V |
| Voltage - Supply (Minimum) | 2.7 V |
