DC1865A
ActiveLT3055EDD DEMO BOARD, MICROPOWER LINEAR REGULATOR, PRECISION CURRENT LIMIT, DIAGNOSTICS, ±45V INPUT VOLTAGES, 2.2V ≤ VIN ≤ 45V, VOUT = 1.2V/1.5V/1.8V/2.5V/3.3V/5V @ 500MA
DC1865A
ActiveLT3055EDD DEMO BOARD, MICROPOWER LINEAR REGULATOR, PRECISION CURRENT LIMIT, DIAGNOSTICS, ±45V INPUT VOLTAGES, 2.2V ≤ VIN ≤ 45V, VOUT = 1.2V/1.5V/1.8V/2.5V/3.3V/5V @ 500MA
Description
General part information
DC1865A
LT3055EDD DEMO BOARD, MICROPOWER LINEAR REGULATOR, PRECISION CURRENT LIMIT, DIAGNOSTICS, ±45V INPUT VOLTAGES, 2.2V ≤ VIN ≤ 45V, VOUT = 1.2V/1.5V/1.8V/2.5V/3.3V/5V @ 500MA
Technical Specifications
Parameters and characteristics for this part
| Specification | DC1865A |
|---|---|
| Channels per IC (Count) | 1 |
| Channels per IC (Single) | 1 |
| Channels per IC (Type) | Single |
| Contents | Board |
| Current - Output | 500 mA |
| Regulator Type | Positive Adjustable |
| Utilized IC / Part | LT3055 |
| Voltage - Input (Maximum) | 45 V |
| Voltage - Input (Minimum) | 5.6 V |
| Voltage - Output | 1.2V, 5V, 2.5V, 1.8V, 1.5V, 3.3V |
| Voltage - Output (Option 1) | 1.2 V |
| Voltage - Output (Option 2) | 1.5 V |
| Voltage - Output (Option 3) | 1.8 V |
| Voltage - Output (Option 4) | 2.5 V |
| Voltage - Output (Option 5) | 3.3 V |
| Voltage - Output (Option 6) | 5 V |
