SR03700001801KR500
ObsoleteVishay Dale
RES 1.8K OHM 1/2W 10% AXIAL
SR03700001801KR500
ObsoleteVishay Dale
RES 1.8K OHM 1/2W 10% AXIAL
Description
General part information
SR03700001801KR500
1.8 kOhms ±10% 0.5W, 1/2W Through Hole Resistor Axial Flame Retardant Coating, Pulse Withstanding, Safety Metal Film
Technical Specifications
Parameters and characteristics for this part
| Specification | SR03700001801KR500 |
|---|---|
| Composition | Metal Film |
| Features | Pulse Withstanding, Safety, Flame Retardant Coating |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Power (Watts) | 500 mW |
| Power (Watts) Options | 1/2W |
| Resistance | 1.8 kOhm |
| Size / Dimension Diameter | 0.157 in |
| Size / Dimension Length | 0.354 in |
| Temperature Coefficient | 250 ppm/°C |
| Temperature Coefficient (Highest) | 250 ppm/°C |
| Temperature Coefficient (Lowest) | -250 ppm/°C |
| Tolerance | 10 % |
