50247-012H0H0-001
ActiveAces Connectors
12PIN, 1.0MM WTB HOUSING WHITE
50247-012H0H0-001
ActiveAces Connectors
12PIN, 1.0MM WTB HOUSING WHITE
Description
General part information
50247-012H0H0-001
12 Position Rectangular Receptacle Connector Crimp Tin 28-32 AWG
Technical Specifications
Parameters and characteristics for this part
| Specification | 50247-012H0H0-001 |
|---|---|
| Cable Termination | Crimp |
| Color | White |
| Connector Type | Receptacle |
| Contact Finish | Tin |
| Contact Type | Female Socket |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 12 |
| Number of Rows | 2 |
| Pitch | 0.039 in |
| Wire Gauge (AWG) (Max) | 32 AWG |
| Wire Gauge (AWG) (Min) | 27.5 AWG |
| Wire Type | Discrete |
