Z60-14-IS510-U
ActiveTDK-LAMBDA
BENCH POWER SUPPLY, ADJUSTABLE, 1 OUTPUT, 0 V, 60 V, 0 A, 14 A
Deep-Dive with AI
Search across all available documentation for this part.
Z60-14-IS510-U
ActiveTDK-LAMBDA
BENCH POWER SUPPLY, ADJUSTABLE, 1 OUTPUT, 0 V, 60 V, 0 A, 14 A
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | Z60-14-IS510-U |
|---|---|
| Accuracy - Voltmeter; Ammeter | 0.5% + 1 count |
| Current - Output [Max] | 14 A |
| Current - Output [Min] | 0 A |
| Current Regulation - Line | 2 mA |
| Current Regulation - Load | 5 mA |
| Display Type | Digital |
| Features | RS232, USB Interface, Programmable, RS485 |
| Number of Characters | 4 |
| Number of Outputs | 1 |
| Power (Watts) | 840 W |
| Ripple | 6.25 mV |
| Size / Dimension [x] | 13.78 in |
| Size / Dimension [x] | 350 mm |
| Size / Dimension [y] | 4.134 " |
| Size / Dimension [y] | 105 mm |
| Size / Dimension [z] | 3.268 in |
| Size / Dimension [z] | 83 mm |
| Type | Bench (AC to DC) |
| Voltage - Output [Max] | 60 VDC |
| Voltage - Output [Min] | 0 VDC |
| Voltage - Supply [Max] | 265 VAC |
| Voltage - Supply [Min] | 85 VAC |
| Voltage Regulation - Load | 2 mV |
| Weight | 2.4 kg |
| Weight | 5.3 lbs |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
Z60-14-IS510-U
0 ~ 60VDC Output Bench (AC to DC) Power Supply Digital 0 ~ 14A Output 840W Features Programmable, RS232, RS485 and USB Interface
