1.10.071.001/0661
ActiveRAFI USA
LED PANEL IND BLU 24V IP66/67/69
Deep-Dive with AI
Search across all available documentation for this part.
1.10.071.001/0661
ActiveRAFI USA
LED PANEL IND BLU 24V IP66/67/69
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 1.10.071.001/0661 | 1.10.071.001 Series |
|---|---|---|
| Current | 25 mA | 25 mA |
| Ingress Protection | IP67, IP69, IP66 | IP67, IP69, IP66 |
| Lamp Color | Blue | White, Blue, Red, Yellow |
| Lens Color | Blue | White, Blue, Red, Yellow |
| Lens Size | - | 29.8 mm |
| Lens Style | Round with Domed Top | Round with Domed Top |
| Panel Cutout Dimensions | 0.88 in | 0.88 in |
| Panel Cutout Dimensions | 22.3 mm | 22.3 mm |
| Panel Cutout Shape | Round | Round |
| Ratings | DC | DC |
| Type | LED | LED |
| Voltage | 24 V | 24 V |
1.10.071.001 Series
LED PANEL IND WHT 24V IP66/67/69
| Part | Type | Panel Cutout Dimensions | Panel Cutout Dimensions | Lens Color | Current | Lamp Color | Panel Cutout Shape | Lens Style | Ingress Protection | Voltage | Ratings | Lens Size [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
RAFI USA 1.10.071.001/0221 | LED | 0.88 in | 22.3 mm | White | 25 mA | White | Round | Round with Domed Top | IP66, IP67, IP69 | 24 V | DC | |
RAFI USA 1.10.071.001/0551 | LED | 0.88 in | 22.3 mm | 25 mA | Round | IP66, IP67, IP69 | 24 V | DC | 29.8 mm | |||
RAFI USA 1.10.071.001/0661 | LED | 0.88 in | 22.3 mm | Blue | 25 mA | Blue | Round | Round with Domed Top | IP66, IP67, IP69 | 24 V | DC | |
RAFI USA 1.10.071.001/0331 | LED | 0.88 in | 22.3 mm | Red | 25 mA | Red | Round | Round with Domed Top | IP66, IP67, IP69 | 24 V | DC | |
RAFI USA 1.10.071.001/0441 | LED | 0.88 in | 22.3 mm | Yellow | 25 mA | Yellow | Round | Round with Domed Top | IP66, IP67, IP69 | 24 V | DC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 38.10 | |
| 10 | $ 35.10 | |||
Description
General part information
1.10.071.001 Series
LED Panel Indicator Blue 24V 25mA
