CSB-115A-5-5S
ActiveR-K Electronics, Inc.
RELAY TIME DELAY 5SEC 10A 120V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CSB-115A-5-5S
ActiveR-K Electronics, Inc.
RELAY TIME DELAY 5SEC 10A 120V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | CSB-115A-5-5S | CSB-115 Series |
|---|---|---|
| Circuit | - | DPDT (2 Form C) |
| Contact Rating @ Voltage | 10 A | 10 A |
| Contact Rating @ Voltage [Max] | 240 VAC | 240 VAC |
| Contact Rating @ Voltage [Min] | 120 VAC | 120 VAC |
| Delay Time [Max] | 5 Sec | 0.5 - 30 Sec |
| Delay Time [Min] | 0.05 Sec | 0.05 - 36 Sec |
| Function | One Shot | One Shot |
| Mounting Type | Socketable | Socketable |
| Relay Type | Mechanical Relay | Mechanical Relay |
| Termination Style | Plug In, 8 Pin (Octal) | Plug In, 11 Pin, Plug In, 8 Pin (Octal), Plug In, 11 Pin (Octal), Plug In |
| Timing Adjustment Method | Hand Dial | Hand Dial, Fixed |
| Timing Initiate Method | Input Voltage | Input Voltage |
| Voltage - Supply | 115 VAC | 115 VAC |
CSB-115 Series
RELAY TIME DELAY 1SEC 10A 120V
| Part | Function | Delay Time [Min] | Delay Time [Max] | Timing Initiate Method | Circuit | Termination Style | Relay Type | Mounting Type | Voltage - Supply | Contact Rating @ Voltage [Min] | Contact Rating @ Voltage | Contact Rating @ Voltage [Max] | Timing Adjustment Method |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
R-K Electronics, Inc. CSB-115A-5B-1S | One Shot | 0.05 Sec | 1 Sec | Input Voltage | DPDT (2 Form C) | Plug In, 11 Pin | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Hand Dial |
R-K Electronics, Inc. CSB-115A-5-30S | One Shot | 0.3 Sec | 30 Sec | Input Voltage | Plug In, 8 Pin (Octal) | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Hand Dial | |
R-K Electronics, Inc. CSB-115A-5B-3M | One Shot | 1.8 Sec | 3 Min | Input Voltage | DPDT (2 Form C) | Plug In, 11 Pin | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Hand Dial |
R-K Electronics, Inc. CSB-115A-2-.5S | One Shot | 0.05 Sec | 0.5 s | Input Voltage | DPDT (2 Form C) | Plug In, 11 Pin (Octal) | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Hand Dial |
R-K Electronics, Inc. CSB-115A-5-5M | One Shot | 3 Sec | 5 Min | Input Voltage | Plug In, 8 Pin (Octal) | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Hand Dial | |
R-K Electronics, Inc. CSB-115A-2-30S | One Shot | 0.3 Sec | 30 Sec | Input Voltage | DPDT (2 Form C) | Plug In, 11 Pin (Octal) | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Hand Dial |
R-K Electronics, Inc. CSB-115A-5-1H | One Shot | 36 Sec | 1 Year | Input Voltage | Plug In, 8 Pin (Octal) | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Hand Dial | |
R-K Electronics, Inc. CSB-115A-4-5S | One Shot | 0.05 Sec | 5 Sec | Input Voltage | Plug In, 8 Pin (Octal) | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Fixed | |
R-K Electronics, Inc. CSB-115A-5-1S | One Shot | 0.05 Sec | 1 Sec | Input Voltage | Plug In, 8 Pin (Octal) | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Hand Dial | |
R-K Electronics, Inc. CSB-115A-5-20M | One Shot | 12 Sec | 20 Min | Input Voltage | Plug In, 8 Pin (Octal) | Mechanical Relay | Socketable | 115 VAC | 120 VAC | 10 A | 240 VAC | Hand Dial |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 190.00 | |
| 5 | $ 135.00 | |||
| 10 | $ 121.50 | |||
Description
General part information
CSB-115 Series
One Shot Time Delay Relay SPDT (1 Form C) 0.05 Sec ~ 5 Sec Delay 10A @ 120/240VAC Socketable
