HT46C/4P-M12

Active

Leuze

DIFFUSE BACKGROUND SUPPRESSION

Search across all available documentation for this part.

Active

Leuze

DIFFUSE BACKGROUND SUPPRESSION

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	HT46C/4P-M12	HT46C Series

Adjustment Type	Adjustable	Adjustable
Connection Method	Connector, M12	Connector, M12
Ingress Protection	IEC 60947-5-2 IP67, IEC 60947-5-2 IP69K, IP67, IEC 60947-5-2, IP69K	IEC 60947-5-2 IP67, IEC 60947-5-2 IP69K, IP67, IEC 60947-5-2, IP69K
Light Source	Red LED	Red LED, Infrared
Light Source	-	860 nm
Operating Temperature [Max]	60 °C	60 °C
Operating Temperature [Min]	-40 °C	-40 °C
Output Configuration	PNP - Dark-ON/Light-ON	PNP - Dark-ON/Light-ON
Response Time	2 ms	2 ms
Sensing Method	Diffuse, Background Suppression	Diffuse, Background Suppression
Voltage - Supply [Max]	30 VDC	30 VDC
Voltage - Supply [Min]	10 VDC	10 VDC

DIFFUSE BACKGROUND SUPPRESSION

Part	Sensing Method	Voltage - Supply [Max]	Voltage - Supply [Min]	Ingress Protection	Response Time	Output Configuration	Connection Method	Light Source	Adjustment Type	Operating Temperature [Min]	Operating Temperature [Max]	Light Source
Leuze HT46C/4P-M12	Background Suppression, Diffuse	30 VDC	10 VDC	IEC 60947-5-2, IEC 60947-5-2 IP67, IEC 60947-5-2 IP69K, IP67, IP69K	2 ms	PNP - Dark-ON/Light-ON	Connector, M12	Red LED	Adjustable	-40 °C	60 °C
Leuze HT46CI/4P-M12	Background Suppression, Diffuse	30 VDC	10 VDC	IEC 60947-5-2 IP67, IEC 60947-5-2 IP69K	2 ms	PNP - Dark-ON/Light-ON	Connector, M12	Infrared		-40 °C	60 °C	860 nm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 216.74

General part information

Diffuse, Background Suppression Optical Sensor 0.197" ~ 118.110" (5mm ~ 3m) PNP - Dark-ON/Light-ON
