KS2,5
ActiveElpress Inc.
BUTT SPLICE 2.5 MM2 / 16-14 AWG
KS2,5
ActiveElpress Inc.
BUTT SPLICE 2.5 MM2 / 16-14 AWG
Description
General part information
KS2,5
Terminal Butt Splice, Inline, Individual Openings Connector Crimp 2.5mm², 16-14 AWG
Technical Specifications
Parameters and characteristics for this part
| Specification | KS2,5 |
|---|---|
| Features | Inspection Hole, UL Listed, Internal Cable Stop |
| Insulation | Non-Insulated |
| Number of Wire Entries | 2 |
| Terminal Type | Inline, Individual Openings, Butt Splice |
| Termination | Crimp |
| Wire Gauge (AWG) (Max) | 14 AWG |
| Wire Gauge (AWG) (Min) | 16 AWG |
| Wire Gauge (Cross-Sectional Area) | 2.5 mm² |
