9002-05-00
ActiveCoto Technology
RELAY RF SPST-NO 500MA 5V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
9002-05-00
ActiveCoto Technology
RELAY RF SPST-NO 500MA 5V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 9002-05-00 |
|---|---|
| Coil Current | 14.3 mA |
| Coil Resistance | 350 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 5 VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 0.5 A |
| Mounting Type | Through Hole |
| Must Operate Voltage | 3.75 VDC |
| Must Release Voltage | 0.4 VDC |
| Operate Time | 0.35 ms |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -20 C |
| Release Time | 0.1 ms |
| Switching Voltage | 200 VDC, 200 VAC |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 7.09 | |
| 10 | $ 6.19 | |||
| 25 | $ 5.87 | |||
| 50 | $ 5.63 | |||
| 100 | $ 5.41 | |||
| 250 | $ 5.13 | |||
| 500 | $ 4.92 | |||
| 1000 | $ 4.73 | |||
Description
General part information
9002-05-00
RELAY RF SPST-NO 500MA 5V
Documents
Technical documentation and resources
