MS27468E19F32PB

Active

Corsair

PLUG ANGLED

Search across all available documentation for this part.

Active

Corsair

PLUG ANGLED

Technical Specifications

Parameters and characteristics for this part

Specification	MS27468E19F32PB

Applications	Military, Aerospace
Connector Type	Plug, Male Pins
Contact Finish - Mating	Gold
Fastening Type	Bayonet Lock
Features	Coupling Nut
Grade	Military
Ingress Protection	IP67
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Front Side Nut
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-65 ░C
Orientation	B
Primary Material	Metal
Qualification	MIL-DTL-38999 Series I
Shell Size, MIL	E
Shielding	Shielded
Termination	Crimp

PLUG ANGLED

Part	Shell Size, MIL	Grade	Orientation	Qualification	Connector Type	Material Flammability Rating	Shielding	Mounting Feature	Features	Primary Material	Applications	Termination	Insert Material	Operating Temperature [Min]	Operating Temperature [Max]	Fastening Type	Ingress Protection	Contact Finish - Mating
Corsair MS27468E19F32PB	E	Military	B	MIL-DTL-38999 Series I	Male Pins, Plug	UL94 V-0	Shielded	Bulkhead - Front Side Nut	Coupling Nut	Metal	Aerospace, Military	Crimp	Thermoplastic	-65 ░C	200 °C	Bayonet Lock	IP67	Gold

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Position Circular Connector Plug, Male Pins Crimp
