MAX11612EVSYS+
ActiveAnalog Devices Inc./Maxim Integrated
EVALUATION SYSTEM FOR MAX11612
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX11612EVSYS+
ActiveAnalog Devices Inc./Maxim Integrated
EVALUATION SYSTEM FOR MAX11612
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX11612EVSYS+ | MAX11612 Series |
|---|---|---|
| Architecture | - | SAR |
| Configuration | - | MUX-S/H-ADC |
| Data Interface | Serial, I2C | I2C, Serial |
| Input Type | - | Single Ended, Differential |
| Mounting Type | - | Surface Mount |
| Number of A/D Converters | 1 | 1 |
| Number of Bits | 10, 8, 12 | 8 - 12 bits |
| Number of Inputs | - | 2 - 4 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 8-MSOP, 8-TSSOP |
| Package / Case | - | 0.118 in |
| Package / Case | - | 3 mm |
| Ratio - S/H:ADC | - | 1:1 |
| Reference Type | - | External, Internal |
| Sampling Rate (Per Second) | 94.4 k per second | 94.4 k per second |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 8-uMAX/uSOP |
| Utilized IC / Part | MAX11612 | MAX11612 |
| Voltage - Supply, Analog | - | 5 V |
| Voltage - Supply, Digital | - | 5 V |
MAX11612 Series
IC ADC 12BIT SAR 8UMAX
| Part | Sampling Rate (Per Second) | Number of Inputs | Number of A/D Converters | Configuration | Data Interface | Voltage - Supply, Analog | Number of Bits | Operating Temperature [Max] | Operating Temperature [Min] | Supplier Device Package | Package / Case | Package / Case [custom] | Package / Case | Reference Type | Architecture | Voltage - Supply, Digital | Input Type | Ratio - S/H:ADC | Mounting Type | Supplied Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX11612EUA+T | 94.4 k per second | 2, 4 | 1 | MUX-S/H-ADC | I2C | 5 V | 12 bits | 85 °C | -40 °C | 8-uMAX/uSOP | 8-MSOP, 8-TSSOP | 0.118 in | 3 mm | External, Internal | SAR | 5 V | Differential, Single Ended | 1:1 | Surface Mount | ||
Analog Devices Inc./Maxim Integrated MAX11612EVSYS+ | 94.4 k per second | 1 | I2C, Serial | 8, 10, 12 | Board(s) | MAX11612 | |||||||||||||||
Analog Devices Inc./Maxim Integrated MAX11612EUA+ | 94.4 k per second | 2, 4 | 1 | MUX-S/H-ADC | I2C | 5 V | 12 bits | 85 °C | -40 °C | 8-uMAX/uSOP | 8-MSOP, 8-TSSOP | 0.118 in | 3 mm | External, Internal | SAR | 5 V | Differential, Single Ended | 1:1 | Surface Mount |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 217.65 | |
Description
General part information
MAX11612 Series
MAX11612 - 8, 10, 12 Bit 94.4k Samples per Second Analog to Digital Converter (ADC) Evaluation Board
