FWG.0B.305.CLA
ActiveLEMO
CONN PLUG MALE 5P GOLD SLDR CUP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FWG.0B.305.CLA
ActiveLEMO
CONN PLUG MALE 5P GOLD SLDR CUP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | FWG.0B.305.CLA | FWG.0B Series |
|---|---|---|
| Backshell Material, Plating | Brass, Chrome | Brass, Chrome |
| Color | Silver | Silver |
| Connector Type | Plug, Male Pins | Plug, Male Pins |
| Contact Finish - Mating | Gold | Gold |
| Contact Finish Thickness - Mating | 1 µm | 1 µm |
| Contact Finish Thickness - Mating | 39.4 µin | 39.4 µin |
| Contact Material | Brass | Brass |
| Current Rating (Amps) | 6.5 A | 2 - 7 A |
| Fastening Type | Push-Pull | Push-Pull |
| Ingress Protection | IP50 | IP50 |
| Insert Material | Polyetheretherketone (PEEK) | Polyetheretherketone (PEEK) |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Feature | Bulkhead - Rear Side Nut | Bulkhead - Rear Side Nut |
| Number of Positions | - | 4 - 9 |
| Operating Temperature [Max] | 250 °C | 250 °C |
| Operating Temperature [Min] | -55 °C | -55 °C |
| Orientation | G | G |
| Primary Material | Metal | Metal |
| Shell Finish | Chrome | Chrome |
| Shell Material | Brass | Brass |
| Shell Size - Insert | 305 | 304 - 309 |
| Shielding | Shielded | Shielded |
| Termination | - | Crimp |
FWG.0B Series
CONN PLUG MALE 9P GOLD SLDR CUP
| Part | Contact Finish - Mating | Connector Type | Insert Material | Fastening Type | Ingress Protection | Shielding | Mounting Feature | Orientation | Operating Temperature [Min] | Operating Temperature [Max] | Primary Material | Color | Material Flammability Rating | Shell Finish | Shell Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Material | Current Rating (Amps) | Backshell Material, Plating | Number of Positions | Shell Size - Insert | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LEMO FWG.0B.309.CLA | Gold | Male Pins, Plug | Polyetheretherketone (PEEK) | Push-Pull | IP50 | Shielded | Bulkhead - Rear Side Nut | G | -55 °C | 250 °C | Metal | Silver | UL94 V-0 | Chrome | Brass | 1 µm | 39.4 µin | Brass | 2 A | Brass, Chrome | 9 | 309 | |
LEMO FWG.0B.305.CLA | Gold | Male Pins, Plug | Polyetheretherketone (PEEK) | Push-Pull | IP50 | Shielded | Bulkhead - Rear Side Nut | G | -55 °C | 250 °C | Metal | Silver | UL94 V-0 | Chrome | Brass | 1 µm | 39.4 µin | Brass | 6.5 A | Brass, Chrome | 305 | ||
LEMO FWG.0B.304.CYC | Gold | Male Pins, Plug | Polyetheretherketone (PEEK) | Push-Pull | IP50 | Shielded | Bulkhead - Rear Side Nut | G | -55 °C | 250 °C | Metal | Silver | UL94 V-0 | Chrome | Brass | 1 µm | 39.4 µin | Brass | 7 A | Brass, Chrome | 4 | 304 | Crimp |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 110.69 | |
| 10 | $ 101.58 | |||
| 25 | $ 97.67 | |||
| 50 | $ 94.42 | |||
| 100 | $ 89.21 | |||
Description
General part information
FWG.0B Series
5 Position Circular Connector Plug, Male Pins Solder Cup
