Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 1704836 | PTSPL Series |
|---|---|---|
| Current | 41 A | 41 A |
| Mating Orientation | Horizontal with Board | Horizontal with Board |
| Mounting Type | Through Hole | Through Hole |
| Number of Levels | 1 | 1 |
| Positions Per Level | 1 | 1 |
| Voltage | - | 400 V |
| Wire Gauge [Max] | 14 AWG | 14 AWG |
| Wire Gauge [Min] | 10 AWG | 10 AWG |
| Wire Termination | Screwless - Spring Cage, Tension Clamp | Push-In Spring, Screwless - Leg Spring, Screwless - Spring Cage, Tension Clamp |
PTSPL Series
Fixed Terminal Blocks 41A, 1kV Spring Cage PTSPL-6/1-2x2 2.1
| Part | Number of Levels | Wire Gauge [Min] | Wire Gauge [Max] | Voltage | Current | Wire Termination | Positions Per Level | Mating Orientation | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1705625 | 1 | 10 AWG | 14 AWG | 400 V | 41 A | Push-In Spring, Screwless - Leg Spring | 1 | Horizontal with Board | |
Phoenix Contact 1704836 | 1 | 10 AWG | 14 AWG | 41 A | Screwless - Spring Cage, Tension Clamp | 1 | Horizontal with Board | Through Hole |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
PTSPL Series
Fixed Terminal Blocks 41A, 1kV Spring Cage PTSPL-6/1-2x2 2.1
