ABL8BPK24A12
ObsoleteBATTERY CONTROL MODULE, 24V, 75A, 12AH, 0 °C TO 40 °C
ABL8BPK24A12
ObsoleteBATTERY CONTROL MODULE, 24V, 75A, 12AH, 0 °C TO 40 °C
Description
General part information
ABL8BPK24A12
ABL8BPK24A12 is a battery module. It has a rated output current of 75A at 24VDC. This backup battery (storage capacity 7Ah) is designed to provide continuous auxiliary power during significant and long network power shortages. It provides long-term backup power for power blackouts lasting more than a few seconds. It weighs 6,500kg. It is a functional module for power supply for industrial use, and rail mounting. It is certified by GOST, UL. This functional module is mainly compatible with Modicon ABL8RP and Modicon ABL8WP Universal power supplies. It has an LED diagnostics indicator available in the front for troubleshooting instantly. It installs on the DIN rail. It brings energy to your automated systems.
Technical Specifications
Parameters and characteristics for this part
| Specification | ABL8BPK24A12 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, UL |
| Current - Output (Max) | 75 A |
| DC Voltage - Input (Max) | 29 V |
| DC Voltage - Input (Min) | 21 V |
| Input Type | DC |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 40 °C |
| Operating Temperature (Min) | 0 °C |
| Size / Dimension Height | 7.68 in |
| Size / Dimension Length | 12.99 in |
| Size / Dimension Width | 7.87 in |
| Voltage - Output 1 | 24 V |
