XPEBGR-L1-0000-00G01-SB01

Obsolete

New Energy

LED MOD XLAMP GREEN STARBOARD

Search across all available documentation for this part.

Obsolete

New Energy

LED MOD XLAMP GREEN STARBOARD

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	XPEBGR-L1-0000-00G01-SB01	XPEBGR Series

Color	Green	Green
Configuration	Starboard	Starboard
Current - Max [Max]	1 A	1 A
Current - Test	350 mA	350 mA
Height	-	2.3 mm
Lens Type	Domed	Domed
Lumens/Watt @ Current - Test	121 lm/W	113 - 121 lm/W
Luminous Flux @ Current/Temperature	135 lm	126 - 135 lm
Size / Dimension [diameter]	19.89 mm	19.89 mm
Type	LED Module	LED Module
Viewing Angle	135 °	135 °
Voltage - Forward (Vf) (Typ)	3.2 V	3.2 V
Wavelength	528 nm	528 - 530 nm
Wavelength [Max]	535 nm	535 nm
Wavelength [Min]	520 nm	520 nm

LED MOD XLAMP GREEN STARBOARD

Part	Current - Test	Size / Dimension [diameter]	Voltage - Forward (Vf) (Typ)	Viewing Angle	Luminous Flux @ Current/Temperature	Color	Type	Configuration	Current - Max [Max]	Lens Type	Lumens/Watt @ Current - Test	Wavelength	Wavelength [Min]	Wavelength [Max]	Height [z]
New Energy XPEBGR-L1-0000-00G01-SB01	350 mA	19.89 mm	3.2 V	135 °	135 lm	Green	LED Module	Starboard	1 A	Domed	121 lm/W	528 nm	520 nm	535 nm
New Energy XPEBGR-L1-0000-00F03-SB01	350 mA	19.89 mm	3.2 V	135 °	126 lm	Green	LED Module	Starboard	1 A	Domed	113 lm/W	530 nm			2.3 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

LED Lighting COBs Engines Modules LED Module XLamp® XP-E2 Green Starboard
