62201-2
ActiveTE Connectivity AMP Connectors
SPLC AMVAR 3000-7000 .020TPBR ROHS COMPLIANT: YES
62201-2
ActiveTE Connectivity AMP Connectors
SPLC AMVAR 3000-7000 .020TPBR ROHS COMPLIANT: YES
Description
General part information
62201-2
Pigtail Splice, 15.5 – 12 AWG, 1.54 – 3.46 mm² Wire, 3 Splice Capacity, Serrated, 3000 – 7000 CMA, Brass, 7 Serration, AMPLIVAR
Technical Specifications
Parameters and characteristics for this part
| Specification | 62201-2 |
|---|---|
| Features | Serrated Mating Area |
| Insulation | Non-Insulated |
| Number of Wire Entries | Varies by Wire Size |
| Terminal Type | Open Band, Crimpband |
| Termination | Crimp |
| Wire Gauge (CMA) (Max) | 7000 CMA |
| Wire Gauge (CMA) (Min) | 3000 CMA |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
