LNCD1-24M
ActiveNDK (NIHON DEMPA KOGYO CO., LTD)
CRYSTAL 24.0000MHZ 8PF SMD
LNCD1-24M
ActiveNDK (NIHON DEMPA KOGYO CO., LTD)
CRYSTAL 24.0000MHZ 8PF SMD
Description
General part information
LNCD1-24M
24 MHz ±50ppm Crystal 8pF 70 Ohms 2-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | LNCD1-24M |
|---|---|
| ESR (Equivalent Series Resistance) | 70 Ohm |
| Frequency | 24 MHz |
| Frequency Stability | 50 ppm |
| Frequency Tolerance | 50 ppm |
| Height - Seated (Max) | 0.059 in |
| Load Capacitance | 8 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -10 °C |
| Package / Case | No Lead, 2-SMD |
| Size / Dimension Length | 0.197 in |
| Size / Dimension Width | 0.126 in |
| Type | MHz Crystal |
