Specification	B32377A7306J020

Applications	3 Phase
Capacitance	30 µF
Dielectric Material	Metallized, Polypropylene (PP)
Height - Seated (Max)	8.209 in
Lead Spacing	0.591 in
Mounting Type	Chassis, Stud Mount
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can, Radial
Size / Dimension Diameter	3.78 in
Termination	Terminal Block
Tolerance	5 %
Voltage Rating - AC	720 V
Voltage Rating - DC	1800 V
