ASI328002
ActiveASI-Ez
RELAY SPDT 6A 24V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ASI328002
ActiveASI-Ez
RELAY SPDT 6A 24V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | ASI328002 | ASI328 Series |
|---|---|---|
| Coil Current | - | 3.2 - 35 mA |
| Coil Voltage | 24 VDC | 12 - 120 VAC |
| Contact Form | SPDT (1 Form C) | SPDT (1 Form C), DPDT (2 Form C), SPDT |
| Contact Rating (Current) | 6 A | 6 - 8 A |
| Mounting Type | DIN Rail | DIN Rail |
| Operate Time | 8 ms | 8 - 15 ms |
| Release Time | 4 ms | 4 - 8 ms |
| Switching Voltage | 250 VAC | 250 VAC |
| Termination Style | Screw Terminal | Spring Terminal, Screw Terminal, Screw Clamp |
ASI328 Series
RELAY SPDT 6A 24V
| Part | Coil Voltage | Mounting Type | Termination Style | Operate Time | Contact Rating (Current) | Contact Form | Switching Voltage | Release Time | Coil Current |
|---|---|---|---|---|---|---|---|---|---|
ASI-Ez ASI328044 | 24 VAC | DIN Rail | Spring Terminal | 8 ms | 6 A | SPDT (1 Form C) | 250 VAC | 4 ms | |
ASI-Ez ASI328043 | 24 VDC | DIN Rail | Spring Terminal | 8 ms | 6 A | SPDT (1 Form C) | 250 VAC | 4 ms | |
ASI-Ez ASI328040 | 120 VAC, 120 VDC | DIN Rail | Screw Terminal | 8 ms | 6 A | SPDT (1 Form C) | 250 VAC | 4 ms | 3.2 mA |
ASI-Ez ASI328007 | 120 VAC, 120 VDC | DIN Rail | Screw Terminal | 8 ms | 6 A | SPDT (1 Form C) | 250 VAC | 4 ms | 3.2 mA |
ASI-Ez ASI328011 | 12 VDC | DIN Rail | Screw Terminal | 15 ms | 8 A | DPDT (2 Form C) | 250 VAC | 8 ms | 35 mA |
ASI-Ez ASI328002 | 24 VDC | DIN Rail | Screw Terminal | 8 ms | 6 A | SPDT (1 Form C) | 250 VAC | 4 ms | |
ASI-Ez ASI328013 | 24 VAC | DIN Rail | Screw Terminal | 15 ms | 8 A | DPDT (2 Form C) | 250 VAC | 8 ms | 18 mA |
ASI-Ez ASI328003 | 24 VAC | DIN Rail | Screw Terminal | 8 ms | 6 A | SPDT (1 Form C) | 250 VAC | 4 ms | |
ASI-Ez ASI328037 | 24 VAC | DIN Rail | Screw Terminal | 8 ms | 6 A | SPDT (1 Form C) | 250 VAC | 4 ms | |
ASI-Ez ASI328047 | 120 VAC, 120 VDC | DIN Rail | Spring Terminal | 8 ms | 6 A | SPDT (1 Form C) | 250 VAC | 4 ms | 3.5 mA |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 12.00 | |
Description
General part information
ASI328 Series
Relay SPDT (1 Form C) 24VDC Coil DIN Rail
