C016 20H003 800 17

Active

Amphenol Tuchel Industrial

CONN PLUG MALE 4POS SCREW

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

CONN PLUG MALE 4POS SCREW

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

4 Position Circular Connector Plug, Male Pins Screw

Technical documentation and resources

Parameters and characteristics commom to parts in this series

CONN PLUG MALE 4POS GOLD SCREW

Part	Number of Positions	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Amps)	Mounting Type	Primary Material	Ingress Protection	Termination	Contact Finish - Mating	Orientation	Voltage Rating	Connector Type	Features
Amphenol Tuchel Industrial C016 20H003 804 12	4	100 °C	-40 °C	16 A	Free Hanging (In-Line)	Plastic	IP65, IP67	Screw	Gold	Keyed	400 V	Male Pins, Plug
Amphenol Tuchel Industrial C016 20H003 800 11	4	100 °C	-40 °C	16 A	Free Hanging (In-Line)	Plastic	IP65, IP67	Screw		Keyed	400 V	Male Pins, Plug	Cable Clamp
Amphenol Tuchel Industrial C016 20H003 210 10	4	100 °C	-40 °C	16 A	Free Hanging (In-Line)	Plastic	IP65, IP67	Screw	Gold	Keyed	400 V	Male Pins, Plug	Cable Clamp, Strain Relief
Amphenol Tuchel Industrial C016 20H003 800 17	4	100 °C	-40 °C	16 A	Free Hanging (In-Line)	Plastic	IP65, IP67	Screw		Keyed	400 V	Male Pins, Plug	Cable Clamp
Amphenol Tuchel Industrial C016 20H003 200 12	4	100 °C	-40 °C	16 A	Free Hanging (In-Line)	Plastic	IP65, IP67	Screw	Gold	Keyed	400 V	Male Pins, Plug	Cable Clamp
Amphenol Tuchel Industrial C016 20H003 210 12	4	100 °C	-40 °C	16 A	Free Hanging (In-Line)	Plastic	IP65, IP67	Screw	Gold	Keyed	400 V	Male Pins, Plug	Cable Clamp, Strain Relief
Amphenol Tuchel Industrial C016 20H003 800 18	4	100 °C	-40 °C	16 A	Free Hanging (In-Line)	Plastic	IP65, IP67	Screw		Keyed	400 V	Male Pins, Plug	Cable Clamp
