Specification	B32726G0256K000

Applications	DC Filtering, DC Link, Automotive
Capacitance	25 µF
Dielectric Material	Polypropylene (PP)
ESR (Equivalent Series Resistance)	4.2 mOhm
Height - Seated (Max)	1.89 in
Lead Spacing	1.476 in
Mounting Type	Through Hole
Operating Temperature (Max)	135 °C
Operating Temperature (Min)	-55 °C
Package Leads	4 Leads
Package Name	Radial
Ratings	AEC-Q200
Size / Dimension Length	1.654 in
Size / Dimension Width	1.299 in
Termination	PC Pins
Tolerance	10 %
Voltage Rating - DC	1 kV
