Specification	B32676E1475K000

Applications	DC Filtering, DC Link
Capacitance	4.7 µF
Dielectric Material	Metallized, Polypropylene (PP)
Features	Long Life
Height - Seated (Max)	1.555 in
Lead Spacing	1.476 in
Mounting Type	Through Hole
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Package / Case	Radial
Size / Dimension Length	1.654 in
Size / Dimension Width	0.787 in
Termination	PC Pins
Tolerance	10 %
Voltage Rating - DC	750 V
